Aerotech G75J-10A Black Jack Rocket Motor

Required Hardware

The AeroTech Reloadable Motor System RMS is an aluminum cased reusable motor in kit form that is assembled by the user. You will need AeroTech RMS-29/180 motor hardware to build and complete the motor for many reliable flights. Motor hardware is available separately in a complete set, and also as individual parts. Important: High Power RMS reload kits are not compatible with Mid Power RMS products. You will need to set the desired delay time using the 18-38mm Delay Drilling Tool (RDDT), Not Included.

This RMS motor reload utilizes RCSs exclusive Black Jack™ aerospace grade composite propellant formulation, which produces a visible black exhaust plume and a denser dark tracking smoke.

The AeroTech motor reload kit comes with 1 rocket motor reload. Reload kits include all internal motor components and FirstFire™ Initiators and requires HAZMAT shipping via FEDEX.

Certified by the Tripoli Rocketry Association (TRA), the National Association of Rocketry (NAR) and the Canadian Association of Rocketry (CAR).

• Specifications:

  Motor Diameter: 1.125 inches (29mm)

  Casing Length: 7.25 inches (184mm)

  Hardware Required: RMS-29/180

  Total Impulse: 135.6 N-sec

  Average Thrust: 75.0 newtons

  Peak Thrust: 70.3 N-sec

  Thrust Duration: 2.4 seconds

  Delay Time: adjustable up to 10 seconds

  Propellant Weight: 104 grams

  Motor Weight: 233 grams
